Excellent Display & Rich Interfaces
Attractive 16:9 aspect ratio 7 inch panel, which features with 800×480 resolution, 4-wire resistive touch,
140° / 120° wide viewing angles, 500:1 contrast and 1000 cd/m2 brightness, providing satisfied viewing
experience. Coming with HDMI (support up to 4K 30Hz), VGA , AV & audio input signals to meet different
needs of various professional display applications.
Metal Housing & Open Frame
Whole device with metal housing design, which make a good protection from damage, and good-looking appearance, also extend the
lifetime of monitor. Having a variety of mounting usage in plenty of fields, such as rear(open frame), wall, desktop and roof mounts.
Application Industries
Metal housing design which can be applied in different professional fields. For instance, Human-machine interface, entertainment, retail,
supermarket, mall, advertising player, CCTV monitoring, numerical control machine and intelligent industrial control system, etc.
Structure
Supports rear mount (open frame) with integrated brackets. A metal housing design with slim and
firm features making efficient integration into embedded or other professional display applications.
| Display | |
| Touch panel | 4-wire resistive |
| Size | 7” |
| Resolution | 800 x 480 |
| Brightness | 1000cd/m² |
| Aspect ratio | 16:9 |
| Contrast | 1000:1 |
| Viewing Angle | 140°/120°(H/V) |
| Video Input | |
| HDMI | 1 |
| VGA | 1 |
| Composite | 2 |
| Supported In Formats | |
| HDMI | 720p 50/60, 1080i 50/60, 1080p 50/60, , 2160p 24/25/30 |
| Audio Out | |
| Ear Jack | 3.5mm - 2ch 48kHz 24-bit |
| Built-in Speakers | 1 |
| Power | |
| Operating power | ≤4.5W |
| DC In | DC 12V |
| Environment | |
| Operating Temperature | -20℃~60℃ |
| Storage Temperature | -30℃~70℃ |
| Other | |
| Dimension(LWD) | 226.8×124×34.7 mm, 279.6×195.5×36.1mm(open frame) |
| Weight | 970g / 950g(open frame) |
